STRUCTURE

Diagonal Wheelbase650 mm
Weight (with TB47D battery)2355 g
Weight (with TB48D battery)2431 g
Max. Takeoff Weight3600 g
Expansion Bay Weight45 g
Battery Compartment Weight160 g
Zenmuse X3 Gimbal with Camera Weight247 g

PROPULSION SYSTEM

Motor ModelDJI 3510
Propeller ModelDJI 1345s
ESC ModelDJI E SERIES 620D

OTHER

Operating Temperature-10°C to 40°C

CHARGER

ModelA14-100P1A
Voltage Output26.3 V
Power Rating100 W

BATTERY (OPTIONAL)

NameIntelligent Flight Battery
ModelTB48D
Capacity5700 mAh
Voltage22.8 V
TypeLiPo 6S
Energy129.96 Wh
Net Weight676 g
Operating Temperature-10°C to 40°C
Storage Temperature
  • <3 months: -20° to 45°C
  • >3 months: 22° to 28°C
Charging Temperature0°C to 40°C
Max. Charging Power180 W

PERFORMANCE

Hovering Accuracy (P-Mode With GPS)Vertical: 0.5 m, Horizontal: 2.5 m
Max. Angular VelocityPitch: 300°/s, Yaw: 150°/s
Max. Tilt Angle35°
Max. Speed of Ascent5 m/s
Max. Speed of Descent4 m/s
Max. Wind Resistance10 m/s
Max. Speed
  • 22 m/s (ATTI mode, no payload, no wind)
  • 17 m/s (GPS mode, no payload, no wind)
Hovering Time (with TB47D battery)No payload: 22 min; 500g payload: 17 min;1kg payload: 13 min
Hovering Time (with TB48D battery)No payload: 28 min; 500g payload: 20 min;1kg payload: 16 min
Hovering Time (with two TB47D batteries)No payload: 33 min
Hovering Time (with two TB48D battery)No payload: 40 min
Hovering Time (with TB47D battery and Zenmuse X3)No payload: 19 min
Hovering Time (with TB48D battery and Zenmuse X3)No payload: 23 min

FLIGHT CONTROL SYSTEM

ModelN1

REMOTE CONTROLLER

NameC1
Operating Frequency
  • 5.725~5.825 GHz
  • 922.7MHz~927.7 MHz (Japan)
  • 2.400~2.483 GHz (Lightbridge)
Transmission Distance (unobstructed, free of interference)
  • CE: 3.5 km
  • FCC: 5 km
EIRP
  • 10dBm@900M
  • 13dBm@5.8G
  • 20dBm@2.4G
Video OutputUSB, Mini-HDMI
Power SupplyBuilt-in battery
ChargerDJI approved charger
Dual Users CapabilityMaster-and-Slave control
Mobile Device HolderSupports smartphones and tablets
Output Power9 W
Operating Temperature-10°C to 40°C
Storage Temperature
  • <3 months: -20°C to 45°C
  • >3 months: 22°C to 28°C
Charging Temperature0°C to 40°C
Battery6000 mAh LiPo 2S
Max Mobile Device Width170mm
Matrice 100Central Board12 Months
Motor6 Months
Remote Controller12 Months
Battery6 Months and Charge Cycle less than 200 Times
FrameNo Warranty
PropellerNo Warranty
GuidanceGuidance Core12 Months
Guidance Sensor6 Months
